Oxford Up Stand-aid and Transfer
People are viewing this right now
Description
- Lightweight, and easy to manoeuvre
- Adjustable legs for access around furniture
- Contoured swing-away seat pads
- Ergonomic design considerations
- Compatible sling offer for additional support
The Oxford Up 200 is a uniquely designed manual stand-aid and transfer device, suitable for those who require assistance when standing but are able to contribute effort to the process.
By encouraging user participation, the Oxford Up 200 can play a supportive role in patient rehabilitation, function, and independence.
Specifications:
- Safe Working Load 200 kg (31 st)
- Overall Height (A) 1093mm
- Overall Length (B) 960mm
- Overall Width (C) 633mm
- Legs Open - External Width (D) 840mm
- Legs Open - Internal Width 720mm
- Legs Closed - External Width (E) 585mm
- Legs Closed - Internal Width 470mm
- Leg Height 105mm
- Knee Pad Height (Footplate to top of pad) 480mm
- Foot Plate Height 37mm
- Ground Clearance 17mm
- Turning Radius 1100mm
- Front Castors 75mm
- Rear Castors (Braked) 100mm
Download:
Oxford Up Stand-aid and Transfer
